STANDARD TUBE SOCKETS
STANDARD TUBE SOCKETS
High quality ceramic and plastic sockets for a variety of tube basings. Eight pin octal, nine pin miniature, two sizes of four pin, five pin, and the hard to find seven pin socket for the 6C33C-B tube. We also have shields for nine pin miniature tubes, anode caps for 807 tubes, and ceramic PC mount nine pin and eight pin sockets.
| PART # | DESCIPTION | PRICE (USD) |
| CHASSIS MOUNT | ||
| 8PINB | 8 pin octal w/mounting bracket, Ceramic chassis mount | $2.89 |
| 8PINCLX | 8 pin octal "Celanex" drop in Fender®, "Celanex" chassis mount | $4.89 |
| 8PINF | 8 Pin Fender Replacement Socket. Ceramic Chassis Mount. | $3.89 |
| 8PINLP | 8 pin octal style w/ long pins. Chassis Mount | $3.89 |
| 8PINPLT | 8 Pin Octal "Johnson" style | $4.89 |
| 8BASE | 8 pin octal tube base only. w/pins. | $3.89 |
| 8PINL | High Quality Ceramic Loctal Socket. Also used with 4CX250B, 4CX400A, etc. Same as Svtelana SK2A. | $5.89 |
| 8PINS | 8 pin octal w/snap ring for mounting, Ceramic chassis mount | $5.89 |
| 9PIN | 9 pin miniature (12AX7 type) w/shield, Ceramic chassis mount | $2.89 |
| 9PIN#2 | 9 pin miniature (12AX7 type) w/shield, Ceramic chassis mount. heavy duty Russian made. | $4.89 |
| 9PINF | 9 pin for Fender. Chassis Mount | $3.89 |
| 9PINPL | 9 pin miniature plastic (Fender® pre-amp), Chassis mount | $1.89 |
| PCP | Shield only for 9PINPL | $1.89 |
| 9PINX | 9 pin novar for 6PI45C, Ceramic chassis mount | $7.89 |
| 7PIN | 7 pin miniature Chassis Mount | $3.89 |
| 4PIN#1 | 4 pin for 300B, 811, and 2A3, Ceramic chassis mount | $5.89 |
| 4PIN#2 | 4 pin for 211 and 845, Ceramic chassis mount | $11.89 |
| 4PIN#3 | 300B (fits same cutout as the 8PINCLX) | $6.89 |
| 5PIN | 5 pin for 807, Ceramic chassis mount | $7.89 |
| CAP | Ceramic cap for 807 | $3.89 |
| 7BIG | 7 pin for 6C33C-B, 829B, and 3E29, Ceramic chassis mount- formerly SKTS. | $5.89 |
| SH9B | Tall tube shield for 9 pin socket (fits 6CG7, 12BH7, 6H30). | $1.89 |
| PC MOUNT | ||
| 7PINPC | 7 pin miniature for 6AU6, Ceramic PC mount | $2.89 |
| 8PINPC | 8 pin octal, Ceramic PC mount | $2.89 |
| 9PINPC | 9 pin miniature, Ceramic PC mount | $2.89 |
| 9PINPC#2 | 9 pin PC Porcelain PC Mount | $1.89 |
| 9PINPCF | $2.89 | |
| 12 Pin compactron | $9.89 | |
| 9PINB | 9 pin miniature (EL84) bracket mount without shield. -Does not take a shield, so it is good for power tubes (EL84), rectifiers (6CA4), and other tubes (6H30) where heat dissipation is an issue. | $1.89 |
